CM TWIN BOOSTER

The Grundfos CM Twin Booster set consists of
two identical Grundfos CM pumps connected
in parallel and mounted on a common base
frame and a control cabinet incorporating
motor protection and controller.

APPLICATIONS

• Large houses
• Domestic buildings
• Cottages and villas
• Mid-size Hotels
• Mid-size Hospitals
• Schools

FEATURES

• Non-self-priming, horizontal,
  multistage centrifugal pump
• Enclosure Class: IP 54
• Insulation Class: F
• Automatic start/stop up to
  100 times/hour
• Quiet operation
• Paint application by electrophoresis
  gives the motor and pump CI parts,
  excellent corrosion resistance
• Simple control and alteration between
  pumps, dry running protection, built-in
  relay for ensuring constant and steady
  operation

TWIN SYSTEM INCLUDES

• Suction and discharge manifolds
• Isolating valves
• Non-return valves
• Pressure gauge
• Pressure switch
• Grundfos Controller CS 201 (1 Phase)

CONSTRUCTION

• Pump Shaft: AISI 304
• Chamber: AISI 304
• Impeller: AISI 304
• Inlet & outlet parts: Cast iron
• Manifold : MS CED Coated
